Name: amaran PT4c RGB LED Pixel Tube Light (4')
SKU: PT4C
Availability: InStock

The PT4c RGB LED Pixel Tube Light from amaran is a 4′ long RGBWW LED pixel tube made for image makers who want more unique lighting options and effects in product cinematography. The high-efficiency chipset produces stellar color quality and accurate skin tones throughout its CCT range of 2700 to 10,000K with full green-magenta control, achieving high CRI, TLCI, and SSI values across the board. The design features 16 built-in pixels that can be independently adjusted and assigned an HIS value via the integrated controls or remotely using the Sidus Link app for Bluetooth devices. The PT4c can also be controlled by DMX using the separately available USB-C to DMX Adapter.

Inside its sleek T12 form factor, this lightweight LED tube is powered by an internal, rechargeable lithium-ion battery, which utilizes a ubiquitous USB-C port for easy charging. Each endcap houses a 3/8-16″ threaded mount and has a 5-sided design to position it on flat surfaces without it rolling out of place.

Built-In Lighting Effects

9 System FX: Fireworks, fire, paparazzi, faulty bulb, TV, pulsing, cop car, lightning, party lights
7 Pixel FX: Color fade, color cycle, 1-pixel chase, 2-pixel chase, 3-pixel chase, rainbow, pixel fire

DMX Functionality

DMX control is available via a separately available USB-C to DMX adapter. DMX function adds 14 built-in DMX profiles and DMX loss behaviors.

Create Multiple Shapes

The shape combinations that can be created using the PT4c are endless, with the ability to use separately available splicing connectors to arrange the tubes in multiple 3D shapes. The PT4c can be combined with other PT-Series LED tubes.

Specification

Item Type	1x LED Array LED Light Tube/Wand
Included Storage Case	Yes
Photometrics	180° at 2700K: 28 fc / 303 Lux 180° at 3200K: 28 fc / 306 Lux 180° at 4300K: 29 fc / 316 Lux 180° at 5600K: 30 fc / 332 Lux 180° at 6500K: 30 fc / 330 Lux 180° at 7500K: 29 fc / 322 Lux 180° at 10000K: 27 fc / 297 Lux

Color Temperature	2700 to 10,000K
Color Modes	RGB, Daylight, Tungsten
Color Accuracy Standard	CRI 95 at 5600K TLCI 98 at 5600K CQS 96 at 5600K SSI 75 at 5600K SSI 85 at 3200K TM-30 Rf 92 at 5600K TM-30 Rg 100 at 5600K

Item Type	1x LED Array LED Light Tube/Wand
Included Storage Case	Yes
Lumens	1402
Photometrics	180° at 2700K: 28 fc / 303 Lux at 3.3′ / 1 m 180° at 3200K: 28 fc / 306 Lux at 3.3′ / 1 m 180° at 4300K: 29 fc / 316 Lux at 3.3′ / 1 m 180° at 5600K: 30 fc / 332 Lux at 3.3′ / 1 m 180° at 6500K: 30 fc / 330 Lux at 3.3′ / 1 m 180° at 7500K: 29 fc / 322 Lux at 3.3′ / 1 m 180° at 10000K: 27 fc / 297 Lux at 3.3′ / 1 m
Color Temperature	2700 to 10,000K
Color Modes	RGB, Daylight, Tungsten
Color Accuracy Standard	CRI 95 at 5600K TLCI 98 at 5600K CQS 96 at 5600K SSI 75 at 5600K SSI 85 at 3200K TM-30 Rf 92 at 5600K TM-30 Rg 100 at 5600K
Dimming	Built-In Dimmer
Cooling System	Passive
Beam Angle	180°
Built-In Flash	No
Pixel Zones	16
Preprogrammed Effects	Yes
Umbrella Mount	No
Front Accessory Mount	No

Connectivity

Wireless Remote Control Type	Bluetooth
Mobile App Compatible	Yes: Android & iOS App Name: Sidus Linnk Functionality: Remote Control
Wireless Channels	No
Wireless Groups	No
Wireless Range	262.5′ / 80 m (Bluetooth)

Power & I/O

Power Source	Battery (Built-In)
Inputs/Outputs	Light Fixture To Light Fixture: 1x USB-C Female Power Input
Battery	1x Rechargeable Lithium-Ion, 14.8 VDC, 5200 mAh, 77 Wh (1x Built-In)
Battery Charging	USB-C Wall Charger (Included)
Input Power	5 VDC at 2 A
Included Adapter / Cable	1x USB-C Male to USB-A Male Cable
Inline Switch	No
Power Pass-Thru	No
Power Consumption	32 W

Mounting

Fixture Mounting

2x 3/8″-16 Female Thread
Magnetic

General

Display	LCD
Environmental Resistance	Dust-Resistant (IP20)
Operating Conditions	22 to 72°F / -10 to 40°C
Certifications	CE, FCC, RoHS
Materials	Plastic
Dimensions	ø: 1.7 x H: 47.2″ / ø: 4.2 x H: 120 cm
Weight	3.03 lb / 1.38 kg
