Name: FeelWorld P6X 5.5" 4K HDMI Touchscreen Monitor
SKU: P6X
Availability: InStock

The P6X 5.5″ 4K HDMI Touchscreen Monitor from FeelWorld provides an on-camera monitoring solution while shooting in the field. The monitor features a 1920 x 1080 native resolution with 1000 cd/m² maximum brightness and a 160° viewing angle capable of being viewed in direct sunlight. HDMI input and output ports support up to 4K video from cameras and transmitter units. Upload up to 32 custom 3D LUTs to customize the look of your footage.

A multitude of video assist functions are embedded in the monitor’s UI and easily accessed using the touchscreen and onboard buttons. Power the monitor via an NP-F battery or the USB input port. An 8 VDC output port can power your DSLR or mirrorless camera. Three 1/4″-20 threads on the monitor allow you to secure the included cold shoe adapter or attach additional accessories.

Video Assist Functions

Anamorphic mode (1.33x, 1.6x, 2.0x, 2.0x mag, user-defined)
Center marker
Check field (red, green, blue, mono)
Color temperature adjustment
Display adjustment
Display range
False color (normal, ARRI)
Focus assist
Grid (2×2, 3×3, 4×4, 5×5, 6×6, 7×7, 8×8, 9×9, custom)
HDR
Histogram
Image flip/freeze
Marker color
Overexposure
Pixel to pixel
Safety frames
Scan mode
Vector
Waveform
Zoom mode

Specification

Display Size	5.5″ / 14.0 cm
Native Resolution	1920 x 1080
Touchscreen	Yes
HDR Support	Yes: Hybrid Log Gamma
Video I/O	1x HDMI 2.0 Input 1x HDMI 2.0 Output
Media/Memory Card Slot	No
Video Format	HDMI DCI 4K: 60/50/30/29.97/25/24/23.98 UHD 4K: 60/50/30/29.97/25/24/23.98 1080p: 60/59.94/50/30/29.97/25/24/23.98 1080i: 60/59.94/50 720p: 60/59.94/50/30/29.97/25/24/23.98 576p 576i 480p 480i
Battery	1x L-Series Mount on Fixed Plate
Power Consumption	10 W

Display

Panel Type	IPS-Type LCD
Display Size	5.5″ / 14.0 cm
Native Resolution	1920 x 1080
Aspect Ratio	16:9
Viewing Angle	Horizontal: 160° (80/80) Vertical: 160° (80/80)
Touchscreen	Yes
Maximum Brightness	1000 nits / cd/m²
Contrast Ratio	1000:1
HDR Support	Yes: Hybrid Log Gamma
Image Controls	Anamorphic De-Squeeze, Check Field, False Color, Histogram, Image Flip, Image Freeze, Overscan, Pixel-to-Pixel Zoom, Screen Markers, Vectorscope, Waveform

Inputs/Outputs

Video I/O	1x HDMI 2.0 Input 1x HDMI 2.0 Output
Embedded Audio	HDMI
Audio I/O	1x 1/8″ / 3.5 mm Headphone Output
Built-In Speaker	Stereo
Power I/O	1x Barrel (12 VDC) Input 1x Barrel (8 VDC) Output 1x USB-C (5 VDC) Input
Other I/O	1x USB-C (Firmware/LUT Upload) Input [Shared with Power]
Media/Memory Card Slot	No

Wireless

Wi-Fi	No
Bluetooth	No
Mobile App Compatible	No

Format Support

Video Format

HDMI
DCI 4K: 60/50/30/29.97/25/24/23.98
UHD 4K: 60/50/30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50
720p: 60/59.94/50/30/29.97/25/24/23.98
576p
576i
480p
480i

Power

Input Power	7 to 24 VDC
Battery	1x L-Series Mount on Fixed Plate
Power Consumption	10 W

Mounting

Tripod/Accessory Mounting

Top/Bottom/Right
1x 1/4″-20 Female

General

Environmental Resistance	No
Operating Conditions	-4 to 122°F / -20 to 50°C
Storage Conditions	-22 to 140°F / -30 to 60°C
Material of Construction	Aluminum
Dimensions	5.5 x 3.3 x 0.9″ / 138.5 x 84.5 x 22 mm
Weight	0.55 lb / 249.00 g
