Name: Rode RodeCaster Duo Streaming Mixer for Integrated Audio Production Studio (Black)
SKU: RCP DUO
Availability: InStock

Key Features

For Podcasters, Streamers, and Musicians
2 High-End Mic/Line/Instrument Preamps
4 Faders and Vibrant Color Touchscreen
Multitrack Recording to microSD or USB
Built-In Series IV Wireless Receivers
Studio-Quality APHEX Processing
Quad-Core Audio Engine
Two Headphone Outputs, Stereo Line Out
6 Programmable Pads for Audio, FX & MIDI
Dual USB Ports and Integrated Bluetooth

Designed to elevate your podcasting, and your streaming, music-making, and content creation, the black RODECaster Duo from RODE is a compact and powerful all-in-one audio production solution that delivers all the same revered features and versatility of the RODECaster Pro II in a smaller, more portable form factor. Perfect for those who require fewer audio inputs and a more travel-friendly design, the RODECaster Duo sacrifices none of the qualities or functionalities of its larger sibling, sporting the same high-powered quad-core audio engine, high-gain, low-noise Revolution preamps, APHEX audio processing, and flexible customization.

The RODECaster Duo features two XLR-1/4″ combo inputs for mic- or line-level signals, one stereo pair line output for speakers, two headphone outputs, a microSD card reader for internal multitrack recording, two USB-C host connections, and an ethernet network terminal for hardware or software integrations. Just like the RCPII, you also get intuitive hands on control, such as four assignable mixer faders, six colorful customizable SMART pads for audio, FX, and MIDI triggering, a bright colorful touchscreen, and plenty of buttons and knobs to create engaging content of almost any kind. The RODECaster Duo includes Bluetooth technology and integrated wireless microphone receivers for onboard compatibility with the RODE Wireless GO II and Wireless ME, allowing you to handle just about any usage scenario and any workflow, anywhere.

Channels of I/O	2 Inputs / 4 Outputs
Built-In DSP	Yes
Maximum Sampling Rate	48 kHz / 24-Bit
Number of Microphone Inputs	2
Number of Headphone Mixes	1x Master
Analog Audio I/O	2x Combo XLR-1/4″ TRS Mic/Line Input 2x 1/4″ TRS Line Output 2x 1/4″ TRS Headphone Output
Host Connection	2x USB-C
OS Compatibility	macOS Windows
Power Requirements	AC/DC Power Adapter (Included)

Channels of I/O	2 Inputs / 4 Outputs
Built-In DSP	Yes
Maximum Sampling Rate	48 kHz / 24-Bit
Number of Microphone Inputs	2
Built-In Microphone	No
Number of Headphone Mixes	1x Master

Signal Processing

Pad	No
Gain/Trim Range	-135 +76 dB
High-Pass Filter	No
Solo/Mute	Solo, Mute per Input Channel

Connectivity

Analog Audio I/O	2x Combo XLR-1/4″ TRS Mic/Line Input 2x 1/4″ TRS Line Output 2x 1/4″ TRS Headphone Output
Phantom Power	No
Digital Audio I/O	No
Host Connection	2x USB-C
Host Connection Protocol	USB 3.0 / 3.1/3.2 Gen 1
USB (Non-Host)	No
MIDI I/O	No
Expansion Slots	No
Wireless	Bluetooth *Built-In

Digital Audio

Sample Rates	48 kHz
Bit Depths	24-Bit
Sync Sources	No

Audio Storage & Playback

Media/Memory Card Slot

Single Slot: microSD/microSDHC

Compatibility

OS Compatibility	macOS / Windows
OS Compatibility	macOS Windows
Mobile App Compatible	No
Mobile Device Compatibility	No

Power

Power Requirements	AC/DC Power Adapter (Included)
AC/DC Power Adapter	5 V

Physical

Dimensions	9.3 x 8.9 x 3″ / 235 x 225 x 76 mm
Weight	2.5 lb / 1131.0 g

Product Highlights

Premium boutique-class preamps with a high gain, low noise, and mic/line/instrument combo inputs
Customizable mixer with RGB color coding
Extensively programmable SMART pads for launching sounds, shows, mixer actions, and more
Two built-in wireless receivers (one on each mic channel) compatible with the Wireless GO II and Wireless ME transmitters
iOS-ready dual USB Type-C ports to connect multiple computers or mobile devices
Advanced high-quality Bluetooth input/output, Wi-Fi, Ethernet, and integrated wireless receivers for Series IV transmitter

High-End Preamps

Built to compete with pricey boutique microphone preamplifiers, the Revolution preamps deliver transparency and detail with ultralow noise (just -131.5 dBV) and incredible gain up to 76 dB, which enables ideal recording levels, even for low-output dynamic mics—no mic boosters, lifters, or normalization needed.
Pro-grade Neutrik XLR-1/4″ combo jacks provide connection points for microphones (+48V phantom power is available for condenser mics), line-level sources, or instruments such as electric guitar and bass. Pairs of the analog input channels can be linked to easily record stereo mic setups, synths, DJ mixers, or outboard gear.

Studio-Quality Processing and Effects

Authentic emulations of classic APHEX hardware processors are onboard—Aural Exciter elevates clarity and sheen, Big Bottom adds warm and deep low-frequency punch, and Compellor glues it all together with compression/leveling—as well as other widely used processors including a reverb, delay, pitch shifter, equalizer, high-pass filter, noise gate, de-esser, robot effects, and more.
Use the VoxLab editor to quickly manipulate parameters on several processors via three intuitive controls, or access the advanced editor (onscreen or with a computer) for intricate editing. Use presets, save your own presets, and load them at any time to immediately call up your favorite settings.

6 Programmable SMART Pads

Each SMART pad can trigger audio files such as music or sound bites, activate special effects, send MIDI commands to software or hardware, or execute mixer functions like fades, music ducking, and bleeping.
Bank switching buttons beneath the pads for a plethora of unique actions.
Select the color of your choice for the pad illumination, a convenient way to remember which effect is on which pad.

Customizable Multichannel Mixer

The 7-channel mixer features 4 channels with full-size broadcast-quality physical faders and three virtual channels, with the option to expand via digital hosting and hardware integrations with future updates.
Physical faders and virtual channels are freely assignable to the two analog inputs, USB and Bluetooth interfaces, and SMART pads.
Each channel offers a pan control, mute button, and listen button (pre- or after-fader solo). With channel-specific color coding on the RODECaster Duo, you’ll be able to quickly identify your sources.
