Name: Sony PXW-Z280 4K 3CMOS 1/2" Sensor XDCAM Camcorder
SKU: PXW-Z280V.UC
Availability: InStock

Sony‘s PXW-Z280 4K 3CMOS 1/2″ Sensor XDCAM Camcorder uses a 3CMOS 1/2″-type sensor to capture up to 4K60 video, providing deep depth of field, improved low-light capability, and optimal image quality with excellent HDR performance. This camera’s integrated 17x optical zoom lens has independent focus, iris, and zoom rings and its electronically variable ND filter enables on-the-fly exposure adjustments. The PXW-Z280 camera supports a variety of modern codecs such as XAVC-Intra and XAVC-Long, as well as legacy codecs such as MPEG HD and DVCAM, enabling you to use one camera to shoot 4K, HD, or SD video.

HDR/SDR Dual Production

The PXW-Z280 camera supports S-Log 3 for improved performance, and HLG (Hybrid Log Gamma) which allows you to shoot and deliver footage compatible with both HDR (high dynamic range) and SDR (standard dynamic range) without needing laborious post-production work. You can record in both 4K and HD simultaneously, or output 4K60p via the built-in 12G-SDI output.

17x Zoom Lens

The 17x zoom lens provides a 30.3 to 515mm (35mm equivalent) range, with up to 34x digital zoom in HD, and independent focus, iris, and zoom rings for quick manual adjustments.

Optimal HDR Performance

The PXW-Z380 is ready to fulfill your HDR needs with two workflows:

S-Log3 to capture maximum data for ultimate flexibility in grading.
The Instant HDR Workflow uses HLG (hybrid log-gamma) to quickly shoot, edit, and view content without compromising on imagery.

Fast Autofocus

Face Detection AF enables you to keep your subject in sharp focus even when you change your coverage angle. Choose between Face Priority AF and Face Only AF modes.

Direct Streaming/Dual-Link Cellular

This camera features built-in, dual-band 2.4 and 5 GHz Wi-Fi for RTMP/RTMPS live streaming to popular online platforms. Use your smartphone or tablet to set up a streaming channel, connect the camera via Wi-Fi and you’re ready to go.
The PXW-Z280 is compatible with standard USB cellular dongles from most networks, providing an even more reliable connection.

Interfaces

Dual SxS memory card slots enable you to record in simultaneous, relay, or backup modes.
Two MI (multi-interface) shoes enable you to power wireless microphones, lights, and other compatible accessories.
Audio features include dual XLR inputs with independent volume dials and up to 4-channel audio.

Specification

Image Sensor	1/2″-Type
Effective Sensor Resolution	8.29 Megapixel
Image Stabilization	Optical in Integrated Lens
Max Recording Modes	XAVC-I Up to UHD 4K at 23.98/25/29.97/50/59.94 fps XAVC-L Up to UHD 4K from 1 to 59.94 fps MPEG HD420 4:2:0 Up to 1080p from 1 to 29.97 fps MPEG HD422 4:2:2 Up to 1080p from 1 to 29.97 fps XAVC-L Up to 1080p at 23.98/25/29.97/50/59.94 fps DV 4:2:0 8-Bit Up to 576p at 25 fps
Max Video Output	No
Media/Memory Card Slot	Dual Slot: SxS
Mobile App Compatible	Yes: Android & iOS
Battery	Sony BP-U Series

Imaging

Image Sensor	1/2″-Type 3-Chip CMOS
Effective Sensor Resolution	8.29 Megapixel
Image Stabilization	Optical in Integrated Lens
Built-In ND Filter	Mechanical Filter Wheel with Clear, 2-Stop (1/4), 4-Stop (1/16), 6-Stop (1/64) ND Filters and a 2 to 7 Stop Electronic ND Filter
Capture Type	Video Only

Exposure Control

Shutter Type	Electronic Rolling Shutter
Shutter Speed	1/8000 to 1/24 Second
Shutter Angle	5.6 to 360°
Signal-to-Noise Ratio	Not Specified by Manufacturer
Sensitivity	f/12 at 2000 lux 89.9% Reflectance (1080p59.94 in Standard Mode or 4K59.94 in High Sensitivity Mode) f/13 at 2000 lux 89.9% Reflectance (1080p59.94 in Standard Mode or 4K59.94 in High Sensitivity Mode)
Minimum Illumination	0.0013 Lux
White Balance	Range: 1500 to 50,000K Presets: ATW, AWB, Set A, Set B

Lens

Focal Length	5.6 to 95.2mm (35mm Equivalent: 30.3 to 515mm)
Zoom	17x Optical / 2x Digital
Maximum Aperture	f/1.9
Minimum Aperture	f/16
Minimum Focus Distance	2″ / 5.1 cm (Wide) to 31.5″ / 80 cm (Tele)
Filter Size	77 mm
Control Rings	Focus Zoom Iris

Focus

Focus Mode

Automatic, Manual Focus

Video Capture

Internal Recording	XAVC-I 3840 x 2160 at 23.98/25/29.97/50/59.94 fps (600 Mb/s) 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (222 Mb/s) 1920 x 1080i at 50/59.94 fps (222 Mb/s) 1280 x 720 at 50/59.94 fps (222 Mb/s) XAVC-L 3840 x 2160 from 1 to 59.94 fps (150 Mb/s) 1920 x 1080p from 1 to 59.94 fps (50 Mb/s) 1920 x 1080i at 50/59.94 fps (50 Mb/s) 1280 x 720 from 1 to 59.94 fps (50 Mb/s) MPEG HD420 4:2:0 1920 x 1080p from 1 to 29.97 fps (35 Mb/s) 1920 x 1080i at 50/59.94 fps (35 Mb/s) 1440 x 1080i at 50/59.94 fps (35 Mb/s) 1280 x 720 from 1 to 59.94 fps (35 Mb/s) MPEG HD422 4:2:2 1920 x 1080p from 1 to 29.97 fps (35 to 50 Mb/s) 1920 x 1080i at 50/59.94 fps (35 to 50 Mb/s) 1280 x 720 from 1 to 59.94 fps (35 to 50 Mb/s) XAVC-L 1920 x 1080p at 23.98/25/29.97/50/59.94 fps (35 Mb/s) 1920 x 1080i at 50/59.94 fps (25 to 35 Mb/s) DV 4:2:0 8-Bit 720 x 576p at 25 fps (25 Mb/s) 720 x 576i at 50 fps (25 Mb/s) 720 x 480p at 29.97 fps (25 Mb/s) 720 x 480i at 59.94 fps (25 Mb/s)
Video Output	No
Fast-/Slow-Motion Support	Yes
Interval Recording Modes	No
Built-In Microphone	Stereo
Audio Recording	XAVC: 4-Channel, 24-Bit at 48 kHz via LPCM Audio
IP Streaming	No

Interface

Media/Memory Card Slot	Dual Slot: SxS
Internal Storage	No
Video I/O	1x BNC (Composite) Output 1x BNC (12G-SDI) Output 1x HDMI Output
Audio I/O	2x XLR 3-Pin Microphone Input 1x 1/8″ / 3.5 mm TRS Stereo Headphone Output
Other I/O	1x BNC (Timecode) Input 1x BNC (Timecode) Output 1x BNC (Genlock) Input 1x 2.5 mm Sub-Mini (LANC) Control 1x Micro-USB Data 1x USB-A 1x USB-C 1x RJ45 (LAN) Data
Wireless	Wi-Fi 5 (802.11ac) / NFC
Mobile App Compatible	Yes: Android & iOS
Global Positioning (GPS, GLONASS, etc.)	GPS

Monitor

Display Type	Primary Monitor: Articulating 3.5″ Non-Touchscreen LCD
Resolution	Primary Monitor: 2,360,000 Dot

Viewfinder

Type	Electronic (OLED)
Resolution	2,360,000 Dot

Power

Battery

Sony BP-U Series

Environmental

Operating Conditions	32 to 104°F / 0 to 40°C
Storage Conditions	-4 to 140°F / -20 to 60°C

General

Shoe Mount	1x Intelligent Hot Shoe
Tripod Mount	1x 1/4″-20 Female 1x 3/8″-16 Female
Dimensions (W x H x D)	7 x 8 x 16.8″ / 178.4 x 202 x 426.3 mm (With Protrusions)
Weight	6.61 lb / 3 kg (With Battery, Recording Media)
